Volume Matrix Pro [ChartNation]

Volume Matrix Pro is a comprehensive volume profile indicator that combines delta-colored volume distribution analysis with adaptive pivot detection and automated volume node identification. The indicator visualizes where institutional volume accumulated at specific price levels, providing traders with precise entry zones backed by actual trading data.

KEY FEATURES:

• Delta-Colored Volume Profile: Displays volume distribution across price bins with automatic delta coloring - green bins show buyer dominance, red bins show seller control at each price level

• High Volume Nodes (HVN) Detection: Automatically identifies and marks price levels with ≥80% of POC volume using yellow diamond markers - these act as magnetic support/resistance zones where institutions built positions

• Low Volume Nodes (LVN) Detection: Marks thin volume areas with gray diamond markers - zones where price moves quickly with minimal friction, ideal for breakout targets

• Adaptive Smart Pivots: ATR-based pivot detection that automatically adjusts length based on market volatility - catches more swings in low volatility, filters to major reversals in high volatility

• Point of Control (POC) Line: Identifies the price level with maximum traded volume - the market's center of gravity. Line colors by delta: green when buyers dominated, red when sellers controlled the level

• Value Area Lines: Dotted lines marking the 70% value area (configurable 50-98%) with delta-based coloring showing cumulative buyer/seller pressure within the range

• Circle Pivot Markers: Clean visual markers at confirmed pivot points with translucent horizontal lines extending to current bar

• Extend-Until-Touch: Pivot lines automatically retract when price touches them, keeping charts clean and showing active levels only

• Dual Profile Modes: Left-side profile (default) or right-pinned bars ahead of price with fully customizable width and padding

• Volume-Filtered Pivots: Only displays pivots with significant volume backing (≥20% of POC by default) - institutional turning points, not noise


HOW IT WORKS:

• The indicator divides the lookback range (default 200 bars) into volume bins (default 50) and calculates total volume and delta (buying vs selling pressure) at each price level. Each bin is colored green if buyers dominated (close > open majority) or red if sellers controlled (close < open majority).

• High Volume Nodes mark price levels where the most trading occurred - these become magnetic support/resistance zones. The Point of Control identifies the single price with maximum volume, acting as the market's gravitational center.

• Smart Pivots use ATR to adapt to changing volatility, then filter against the volume profile. Only pivots with substantial volume backing are displayed, ensuring you see institutional turning points, not random noise.


RECOMMENDED SETTINGS:

1. Scalping (1-5 min): 100 lookback bars, 40 bins, 5-7 pivot length

2. Day Trading (15 min - 1 hour): 200 lookback bars, 50 bins, 10 pivot length (default)

3. Swing Trading (4 hour - Daily): 300-500 lookback bars, 60 bins, 15-20 pivot length


USAGE TIPS:

• Enter long when price touches green HVN zones with adaptive pivot confirmation

• Enter short when price reaches red HVN zones with pivot confirmation

• Use POC as first target when entering below it, or as support backup when entering above

• Watch for LVN zones as potential breakout acceleration areas

• Combine green delta bins + HVN + pivot for highest-probability setups


WHAT MAKES THIS DIFFERENT:
Unlike traditional volume profiles, Volume Matrix Pro colors each bin individually by delta, giving granular insight into buyer/seller control at every price level. The adaptive pivot system adjusts automatically to volatility, while volume-filtering ensures only institutionally-backed turning points are displayed. High/Low Volume Node detection is fully automated with visual markers.

IMPORTANT NOTES:

• This is a volume analysis tool - use with trend analysis and risk management

• High Volume Nodes show where volume accumulated historically, not future support/resistance guarantees

• Adaptive pivots adjust to volatility automatically but can still produce false signals in choppy markets

• Best used as confirmation alongside price action, not as a standalone system

• Profile recalculates on each bar to reflect current lookback range
